MULTI SPLIT

TABLEAUX DE COMBINAISON

MU5M40

Chaud Chaud
Unité en Combinaison (kBtu/h) Capacité totale Unité en Combinaison (kBtu/h) Capacité totale
fonctionnement Puissance (kW) Min Nom Max Puissance absorbée (W) fonctionnement Puissance (kW) Min Nom Max Puissance absorbée (W)
Unit-A Unit-B Unit-C Unit-D Unit-E Total Unit-A Unit-B Unit-C Unit-D Unit-E Btu/h kW Btu/h kW Btu/h kW Min Nom Max Unit-A Unit-B Unit-C Unit-D Unit-E Total Unit-A Unit-B Unit-C Unit-D Unit-E Btu/h kW Btu/h kW Btu/h kW Min Nom Max
5 5 5 5 20 1.7 1.7 1.7 1.7 - 13,860 4.1 23,100 6.8 27,720 8.1 868 1,400 2,282 5 7 7 7 7 33 1.6 2.2 2.2 2.2 2.2 21,780 6.4 36,300 10.6 43,560 12.8 1,432 2,310 3,765
5 5 5 7 22 1.7 1.7 1.7 2.4 - 15,180 4.4 25,300 7.4 30,360 8.9 955 1,540 2,510 5 5 5 7 12 34 1.6 1.6 1.6 2.3 3.9 22,440 6.6 37,400 11.0 44,880 13.2 1,476 2,380 3,879
5 5 5 9 24 1.6 1.6 1.6 2.9 - 15,840 4.6 26,400 7.7 31,680 9.3 1,042 1,680 2,738 5 5 5 5 15 35 1.6 1.6 1.6 1.6 4.8 23,100 6.8 38,500 11.3 46,200 13.5 1,498 2,415 3,936
5 5 7 7 24 1.6 1.6 2.2 2.2 - 15,840 4.6 26,400 7.7 31,680 9.3 1,042 1,680 2,738 5 7 7 7 9 35 1.6 2.3 2.3 2.3 2.9 23,100 6.8 38,500 11.3 46,200 13.5 1,519 2,450 3,994
5 5 7 9 26 1.6 1.6 2.3 2.9 - 17,160 5.0 28,600 8.4 34,320 10.1 1,128 1,820 2,967 7 7 7 7 7 35 2.3 2.3 2.3 2.3 2.3 23,100 6.8 38,500 11.3 46,200 13.5 1,519 2,450 3,994
5 7 7 7 26 1.6 2.3 2.3 2.3 - 17,160 5.0 28,600 8.4 34,320 10.1 1,128 1,820 2,967 5 5 5 9 12 36 1.6 1.6 1.6 2.9 3.9 23,760 7.0 39,600 11.6 47,520 13.9 1,562 2,520 4,108
5 5 5 12 27 1.6 1.6 1.6 3.9 - 17,820 5.2 29,700 8.7 35,640 10.4 1,172 1,890 3,081 5 5 7 7 12 36 1.6 1.6 2.3 2.3 3.9 23,760 7.0 39,600 11.6 47,520 13.9 1,562 2,520 4,108
5 5 9 9 28 1.6 1.6 2.9 2.9 - 18,480 5.4 30,800 9.0 36,960 10.8 1,215 1,960 3,195 5 5 5 7 15 37 1.6 1.6 1.6 2.3 4.8 24,420 7.2 40,700 11.9 48,840 14.3 1,584 2,555 4,165
5 7 7 9 28 1.6 2.3 2.3 2.9 - 18,480 5.4 30,800 9.0 36,960 10.8 1,215 1,960 3,195 5 5 9 9 9 37 1.6 1.6 2.9 2.9 2.9 24,420 7.2 40,700 11.9 48,840 14.3 1,606 2,590 4,222
7 7 7 7 28 2.3 2.3 2.3 2.3 - 18,480 5.4 30,800 9.0 36,960 10.8 1,215 1,960 3,195 5 7 7 9 9 37 1.6 2.3 2.3 2.9 2.9 24,420 7.2 40,700 11.9 48,840 14.3 1,606 2,590 4,222
5 5 7 12 29 1.6 1.6 2.2 3.8 - 19,140 5.6 31,900 9.3 38,280 11.2 1,259 2,030 3,309 7 7 7 7 9 37 2.3 2.3 2.3 2.3 2.9 24,420 7.2 40,700 11.9 48,840 14.3 1,606 2,590 4,222
5 5 5 15 30 1.6 1.6 1.6 4.9 - 19,800 5.8 33,000 9.7 39,600 11.6 1,281 2,065 3,366 5 5 5 5 18 38 1.6 1.6 1.6 1.6 5.8 25,080 7.4 41,800 12.3 50,160 14.7 1,649 2,660 4,336
5 7 9 9 30 1.6 2.3 2.9 2.9 - 19,800 5.8 33,000 9.7 39,600 11.6 1,302 2,100 3,423 5 7 7 7 12 38 1.6 2.3 2.3 2.3 3.9 25,080 7.4 41,800 12.3 50,160 14.7 1,649 2,660 4,336
7 7 7 9 30 2.3 2.3 2.3 2.9 - 19,800 5.8 33,000 9.7 39,600 11.6 1,302 2,100 3,423 5 5 5 9 15 39 1.6 1.6 1.6 2.9 4.8 25,620 7.5 42,700 12.5 51,240 15.0 1,695 2,735 4,458
5 5 9 12 31 1.6 1.6 2.9 3.9 - 20,460 6.0 34,100 10.0 40,920 12.0 1,345 2,170 3,537 5 5 5 12 12 39 1.6 1.6 1.6 3.8 3.8 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 7 7 12 31 1.6 2.3 2.3 3.9 - 20,460 6.0 34,100 10.0 40,920 12.0 1,345 2,170 3,537 5 5 7 7 15 39 1.6 1.6 2.2 2.2 4.8 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 7 15 32 1.6 1.6 2.3 4.8 - 21,120 6.2 35,200 10.3 42,240 12.4 1,367 2,205 3,594 7 7 7 9 9 39 2.2 2.2 2.2 2.9 2.9 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 9 9 32 2.3 2.3 2.9 2.9 - 21,120 6.2 35,200 10.3 42,240 12.4 1,389 2,240 3,651 5 7 9 9 9 39 1.6 2.2 2.9 2.9 2.9 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 9 9 9 32 1.6 2.9 2.9 2.9 - 21,120 6.2 35,200 10.3 42,240 12.4 1,389 2,240 3,651 5 5 5 7 18 40 1.6 1.6 1.6 2.2 5.6 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 5 18 33 1.6 1.6 1.6 5.8 - 21,780 6.4 36,300 10.6 43,560 12.8 1,432 2,310 3,765 5 5 9 9 12 40 1.6 1.6 2.8 2.8 3.8 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 7 9 12 33 1.6 2.2 2.9 3.9 - 21,780 6.4 36,300 10.6 43,560 12.8 1,432 2,310 3,765 5 7 7 9 12 40 1.6 2.2 2.2 2.8 3.8 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 7 12 33 2.2 2.2 2.2 3.9 - 21,780 6.4 36,300 10.6 43,560 12.8 1,432 2,310 3,765 7 7 7 7 12 40 2.2 2.2 2.2 2.2 3.8 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 9 15 34 1.6 1.6 2.9 4.9 - 22,440 6.6 37,400 11.0 44,880 13.2 1,454 2,345 3,822 5 5 7 9 15 41 1.5 1.5 2.1 2.7 4.6 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 12 12 34 1.6 1.6 3.9 3.9 - 22,440 6.6 37,400 11.0 44,880 13.2 1,476 2,380 3,879 5 7 7 7 15 41 1.5 2.1 2.1 2.1 4.6 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 7 7 15 34 1.6 2.3 2.3 4.9 - 22,440 6.6 37,400 11.0 44,880 13.2 1,476 2,380 3,879 5 9 9 9 9 41 1.5 2.7 2.7 2.7 2.7 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 9 9 9 34 2.3 2.9 2.9 2.9 - 22,440 6.6 37,400 11.0 44,880 13.2 1,476 2,380 3,879 7 7 9 9 9 41 2.1 2.1 2.7 2.7 2.7 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 7 18 35 1.6 1.6 2.3 5.8 - 23,100 6.8 38,500 11.3 46,200 13.5 1,519 2,450 3,994 5 5 5 9 18 42 1.5 1.5 1.5 2.7 5.4 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 9 9 12 35 1.6 2.9 2.9 3.9 - 23,100 6.8 38,500 11.3 46,200 13.5 1,519 2,450 3,994 5 5 5 12 15 42 1.5 1.5 1.5 3.6 4.5 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 9 12 35 2.3 2.3 2.9 3.9 - 23,100 6.8 38,500 11.3 46,200 13.5 1,519 2,450 3,994 5 5 7 7 18 42 1.5 1.5 2.1 2.1 5.4 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 7 9 15 36 1.6 2.3 2.9 4.8 - 23,760 7.0 39,600 11.6 47,520 13.9 1,541 2,485 4,051 5 7 9 9 12 42 1.5 2.1 2.7 2.7 3.6 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 7 12 12 36 1.6 2.3 3.9 3.9 - 23,760 7.0 39,600 11.6 47,520 13.9 1,562 2,520 4,108 7 7 7 9 12 42 2.1 2.1 2.1 2.7 3.6 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 7 15 36 2.3 2.3 2.3 4.8 - 23,760 7.0 39,600 11.6 47,520 13.9 1,562 2,520 4,108 5 5 9 9 15 43 1.5 1.5 2.6 2.6 4.4 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 9 9 9 36 2.9 2.9 2.9 2.9 - 23,760 7.0 39,600 11.6 47,520 13.9 1,562 2,520 4,108 5 7 7 9 15 43 1.5 2.0 2.0 2.6 4.4 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 9 18 37 1.6 1.6 2.9 5.8 - 24,420 7.2 40,700 11.9 48,840 14.3 1,606 2,590 4,222 5 7 7 12 12 43 1.5 2.0 2.0 3.5 3.5 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 12 15 37 1.6 1.6 3.9 4.8 - 24,420 7.2 40,700 11.9 48,840 14.3 1,606 2,590 4,222 7 7 7 7 15 43 2.0 2.0 2.0 2.0 4.4 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 7 7 18 37 1.6 2.3 2.3 5.8 - 24,420 7.2 40,700 11.9 48,840 14.3 1,606 2,590 4,222 7 9 9 9 9 43 2.0 2.6 2.6 2.6 2.6 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 9 9 12 37 2.3 2.9 2.9 3.9 - 24,420 7.2 40,700 11.9 48,840 14.3 1,606 2,590 4,222 5 5 7 12 15 44 1.4 1.4 2.0 3.4 4.3 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 9 9 15 38 1.6 2.9 2.9 4.9 - 25,080 7.4 41,800 12.3 50,160 14.7 1,649 2,660 4,336 5 5 5 5 24 44 1.4 1.4 1.4 1.4 6.8 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 9 15 38 2.3 2.3 2.9 4.9 - 25,080 7.4 41,800 12.3 50,160 14.7 1,649 2,660 4,336 5 7 7 7 18 44 1.4 2.0 2.0 2.0 5.1 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 12 12 38 2.3 2.3 3.9 3.9 - 25,080 7.4 41,800 12.3 50,160 14.7 1,649 2,660 4,336 5 9 9 9 12 44 1.4 2.6 2.6 2.6 3.4 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 5 24 39 1.6 1.6 1.6 7.7 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 9 9 12 44 2.0 2.0 2.6 2.6 3.4 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 7 9 18 39 1.6 2.2 2.9 5.8 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 5 12 18 45 1.4 1.4 1.4 3.3 5.0 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 7 12 15 39 1.6 2.2 3.8 4.8 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 5 15 15 45 1.4 1.4 1.4 4.2 4.2 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 9 9 12 39 2.9 2.9 2.9 3.8 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 7 9 9 15 45 1.4 1.9 2.5 2.5 4.2 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 7 18 39 2.2 2.2 2.2 5.8 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 7 9 12 12 45 1.4 1.9 2.5 3.3 3.3 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 12 18 40 1.6 1.6 3.8 5.6 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 7 9 15 45 1.9 1.9 1.9 2.5 4.2 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 9 9 15 40 2.2 2.8 2.8 4.7 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 9 9 9 9 9 45 2.5 2.5 2.5 2.5 2.5 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 9 12 12 40 2.2 2.8 3.8 3.8 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 5 7 24 46 1.4 1.4 1.4 1.9 6.5 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 MULTI SPLIT
4 Unités 5 5 7 24 41 1.5 1.5 2.1 7.3 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 Unités 5 5 9 9 18 46 1.4 1.4 2.4 2.4 4.9 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 9 12 15 41 1.5 2.7 3.7 4.6 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 9 12 15 46 1.4 1.4 2.4 3.3 4.1 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 12 12 12 41 1.5 3.7 3.7 3.7 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 12 12 12 46 1.4 1.4 3.3 3.3 3.3 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 9 18 41 2.1 2.1 2.7 5.5 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 7 7 9 18 46 1.4 1.9 1.9 2.4 4.9 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 12 15 41 2.1 2.1 3.7 4.6 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 7 7 12 15 46 1.4 1.9 1.9 3.3 4.1 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 7 15 15 42 1.5 2.1 4.5 4.5 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 7 7 18 46 1.9 1.9 1.9 1.9 4.9 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 9 9 15 42 2.7 2.7 2.7 4.5 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 9 9 9 12 46 1.9 2.4 2.4 2.4 3.3 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 9 12 12 42 2.7 2.7 3.6 3.6 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 7 15 15 47 1.3 1.3 1.9 4.0 4.0 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 9 12 15 43 2.0 2.6 3.5 4.4 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 9 9 9 15 47 1.3 2.4 2.4 2.4 4.0 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 12 12 12 43 2.0 3.5 3.5 3.5 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 9 9 12 12 47 1.3 2.4 2.4 3.2 3.2 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 9 9 18 43 2.0 2.6 2.6 5.2 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 9 9 15 47 1.9 1.9 2.4 2.4 4.0 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 9 15 15 44 1.4 2.6 4.3 4.3 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 9 12 12 47 1.9 1.9 2.4 3.2 3.2 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 12 18 44 2.0 2.0 3.4 5.1 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 5 9 24 48 1.3 1.3 1.3 2.3 6.3 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 15 15 44 2.0 2.0 4.3 4.3 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 5 18 15 48 1.3 1.3 1.3 4.7 3.9 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 7 18 15 45 1.4 1.9 5.0 4.2 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 7 7 24 48 1.3 1.3 1.8 1.8 6.3 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 9 12 15 45 2.5 2.5 3.3 4.2 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 7 9 9 18 48 1.3 1.8 2.3 2.3 4.7 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 12 12 12 45 2.5 3.3 3.3 3.3 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 7 9 12 15 48 1.3 1.8 2.3 3.1 3.9 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 9 9 18 45 2.5 2.5 2.5 5.0 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 7 12 12 12 48 1.3 1.8 3.1 3.1 3.1 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 7 24 45 1.9 1.9 1.9 6.7 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 7 12 15 48 1.8 1.8 1.8 3.1 3.9 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 9 12 18 46 1.9 2.4 3.3 4.9 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 9 9 9 9 12 48 2.3 2.3 2.3 2.3 3.1 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 9 15 15 46 1.9 2.4 4.1 4.1 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 7 12 12 45 1.9 1.9 1.9 3.3 3.3 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 12 12 15 46 1.9 3.3 3.3 4.1 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 7 9 18 48 1.8 1.8 1.8 2.3 4.7 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 18 18 46 1.4 1.4 4.9 4.9 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 9 15 15 49 1.3 1.3 2.3 3.8 3.8 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 12 12 18 47 1.3 3.2 3.2 4.8 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 7 7 15 15 49 1.3 1.8 1.8 3.8 3.8 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 9 24 47 1.9 1.9 2.4 6.4 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 9 9 9 15 49 1.8 2.3 2.3 2.3 3.8 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 15 18 47 1.9 1.9 4.0 4.8 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 9 9 12 12 49 1.8 2.3 2.3 3.1 3.1 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 9 15 18 47 1.3 2.4 4.0 4.8 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 7 9 24 50 1.3 1.3 1.8 2.3 6.0 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 12 15 15 47 1.3 3.2 4.0 4.0 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 7 15 18 50 1.3 1.3 1.8 3.8 4.5 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 9 15 15 48 2.3 2.3 3.9 3.9 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 9 9 9 18 50 1.3 2.3 2.3 2.3 4.5 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 7 18 18 48 1.3 1.8 4.7 4.7 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 9 12 12 12 50 1.3 2.3 3.0 3.0 3.0 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
12 12 12 12 48 3.1 3.1 3.1 3.1 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 12 12 12 50 1.8 1.8 3.0 3.0 3.0 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 9 12 18 48 2.3 2.3 3.1 4.7 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 9 9 18 50 1.8 1.8 2.3 2.3 4.5 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 15 24 49 1.3 1.3 3.8 6.1 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 9 12 15 50 1.8 1.8 2.3 3.0 3.8 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 9 15 18 49 1.8 2.3 3.8 4.6 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 7 9 15 15 51 1.2 1.7 2.2 3.7 3.7 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 12 12 18 49 1.8 3.1 3.1 4.6 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 7 12 12 15 51 1.2 1.7 2.9 2.9 3.7 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 12 15 15 49 1.8 3.1 3.8 3.8 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 7 15 15 51 1.7 1.7 1.7 3.7 3.7 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 9 9 24 49 1.8 2.3 2.3 6.1 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 9 9 9 9 15 51 2.2 2.2 2.2 2.2 3.7 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 9 18 18 50 1.3 2.3 4.5 4.5 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 9 9 9 12 12 51 2.2 2.2 2.2 2.9 2.9 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 15 15 15 50 1.3 3.8 3.8 3.8 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 7 12 18 51 1.7 1.7 1.7 2.9 4.4 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 12 24 50 1.8 1.8 3.0 6.0 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 7 15 15 51 1.7 1.7 1.7 3.7 3.7 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 7 18 18 50 1.8 1.8 4.5 4.5 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 9 9 9 9 15 51 2.2 2.2 2.2 2.2 3.7 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 7 15 24 51 1.2 1.7 3.7 5.9 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 9 15 18 52 1.2 1.2 2.2 3.6 4.3 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 9 15 18 51 2.2 2.2 3.7 4.4 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 5 12 15 15 52 1.2 1.2 2.9 3.6 3.6 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 12 12 18 51 2.2 2.9 2.9 4.4 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 5 7 7 15 18 52 1.2 1.7 1.7 3.6 4.3 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 9 9 24 51 2.2 2.2 2.2 5.9 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 9 9 12 15 52 1.7 2.2 2.2 2.9 3.6 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
9 12 15 15 51 2.2 2.9 3.7 3.7 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 9 12 12 12 52 1.7 2.2 2.9 2.9 2.9 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 18 24 52 1.2 1.2 4.3 5.8 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 9 9 9 18 52 1.7 2.2 2.2 2.2 4.3 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 9 12 24 52 1.7 2.2 2.9 5.8 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450 7 7 7 7 24 52 1.7 1.7 1.7 1.7 5.8 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
7 15 15 15 52 1.7 3.6 3.6 3.6 - 25,620 7.5 42,700 12.5 51,200 15.0 1,742 2,810 4,450
5 5 5 5 5 25 1.6 1.6 1.6 1.6 1.6 16,500 4.8 27,500 8.1 33,000 9.7 1,085 1,750 2,853
5 5 5 5 7 27 1.6 1.6 1.6 1.6 2.3 17,820 5.2 29,700 8.7 35,640 10.4 1,172 1,890 3,081
5 5 5 5 9 29 1.6 1.6 1.6 1.6 2.9 19,140 5.6 31,900 9.3 38,280 11.2 1,259 2,030 3,309 Note :
5 5 5 7 7 29 1.6 1.6 1.6 2.2 2.2 19,140 5.6 31,900 9.3 38,280 11.2 1,259 2,030 3,309
5 Unités 5 5 5 7 9 31 1.6 1.6 1.6 2.3 2.9 20,460 6.0 34,100 10.0 40,920 12.0 1,345 2,170 3,537 1. Refroidissement : Intérieur : 27°C BS / 19°C BH, extérieur : 35°C BS / 24°C BH
5 5 7 7 7 31 1.6 1.6 2.3 2.3 2.3 20,460 6.0 34,100 10.0 40,920 12.0 1,345 2,170 3,537 2. Chauffage : Intérieur : 20°C BS / 15°C BH, extérieur : 7°C BS / 6°C BH
5 5 5 5 12 32 1.6 1.6 1.6 1.6 3.9 21,120 6.2 35,200 10.3 42,240 12.4 1,389 2,240 3,651 3. La capacité totale d’une unité intérieure connectée est de 21k Btu/h
5 5 5 9 9 33 1.6 1.6 1.6 2.9 2.9 21,780 6.4 36,300 10.6 43,560 12.8 1,432 2,310 3,765
5 5 7 7 9 33 1.6 1.6 2.2 2.2 2.9 21,780 6.4 36,300 10.6 43,560 12.8 1,432 2,310 3,765 4. Au moins 2 unités intérieures doivent être raccordées.
