MULTI SPLIT
TABLEAUX DE COMBINAISON
MU5R30 / MU5M30
Chaud Chaud
Unité en Combinaison (kBtu/h) Capacité totale Unité en Combinaison (kBtu/h) Capacité totale
fonctionnement Puissance (kW) Min Nom Max Puissance absorbée (W) fonctionnement Puissance (kW) Min Nom Max Puissance absorbée (W)
Unit-A Unit-B Unit-C Unit-D Unit-E Total Unit-A Unit-B Unit-C Unit-D Unit-E Btu/h kW Btu/h kW Btu/h kW Min Nom Max Unit-A Unit-B Unit-C Unit-D Unit-E Total Unit-A Unit-B Unit-C Unit-D Unit-E Btu/h kW Btu/h kW Btu/h kW Min Nom Max
7 18 18 43 1.6 4.2 4.2 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 5 5 5 5 25 1.8 1.8 1.8 1.8 1.8 18,000 5.3 30,000 8.8 36,000 10.6 1,092 1,944 2,877
7 12 24 43 1.6 2.8 5.6 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 5 5 5 7 27 1.8 1.8 1.8 1.8 2.5 19,440 5.7 32,400 9.5 38,880 11.4 1,184 2,129 3,300
5 15 24 44 1.1 3.4 5.5 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 5 5 5 9 29 1.7 1.7 1.7 1.7 3.1 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
9 18 18 45 2.0 4.0 4.0 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 5 5 7 7 29 1.7 1.7 1.7 2.4 2.4 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
9 12 24 45 2.0 2.7 5.4 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 5 5 7 9 31 1.6 1.6 1.6 2.3 2.9 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
12 15 18 45 2.7 3.4 4.0 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 5 7 7 7 31 1.6 1.6 2.3 2.3 2.3 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
3 Unités 15 15 15 45 3.4 3.4 3.4 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 5 5 5 12 32 1.6 1.6 1.6 1.6 3.8 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 15 24 46 1.5 3.3 5.3 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 5 5 9 9 33 1.5 1.5 1.5 2.8 2.8 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 18 24 47 1.1 3.9 5.2 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 5 7 7 9 33 1.5 1.5 2.1 2.1 2.8 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
9 15 24 48 1.9 3.2 5.1 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 7 7 7 7 33 1.5 2.1 2.1 2.1 2.1 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
12 18 18 48 2.5 3.8 3.8 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 5 5 7 12 34 1.5 1.5 1.5 2.1 3.6 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
12 12 24 48 2.5 2.5 5.1 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 5 5 5 15 35 1.4 1.4 1.4 1.4 4.3 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
15 15 18 48 3.2 3.2 3.8 - - 20,700 6.1 34,500 10.1 38,640 11.3 1,394 2,626 3,686 5 7 7 7 9 35 1.4 2.0 2.0 2.0 2.6 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 5 5 20 1.8 1.8 1.8 1.8 - 14,400 4.2 24,000 7.0 28,800 8.4 878 1,547 2,195 7 7 7 7 7 35 2.0 2.0 2.0 2.0 2.0 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 5 7 22 1.8 1.8 1.8 2.5 - 15,840 4.6 26,400 7.7 31,680 9.3 969 1,726 2,527 5 5 5 9 12 36 1.4 1.4 1.4 2.5 3.4 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 5 9 24 1.8 1.8 1.8 3.2 - 17,280 5.1 28,800 8.4 34,560 10.1 1,085 1,909 2,927 5 5 7 7 12 36 1.4 1.4 2.0 2.0 3.4 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 7 7 24 1.8 1.8 2.5 2.5 - 17,280 5.1 28,800 8.4 34,560 10.1 1,085 1,909 2,927 5 5 5 7 15 37 1.4 1.4 1.4 1.9 4.1 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 7 9 26 1.8 1.8 2.5 3.2 - 18,720 5.5 31,200 9.1 37,440 11.0 1,180 2,116 3,427 5 5 9 9 9 37 1.4 1.4 2.5 2.5 2.5 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 7 7 7 26 1.8 2.5 2.5 2.5 - 18,720 5.5 31,200 9.1 37,440 11.0 1,180 2,116 3,427 5 7 7 9 9 37 1.4 1.9 1.9 2.5 2.5 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 5 12 27 1.8 1.8 1.8 4.2 - 19,440 5.7 32,400 9.5 38,640 11.3 1,227 2,281 3,606 7 7 7 7 9 37 1.9 1.9 1.9 1.9 2.5 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 9 9 28 1.8 1.8 3.2 3.2 - 20,160 5.9 33,600 9.8 38,640 11.3 1,276 2,411 3,606 5 5 5 5 18 38 1.3 1.3 1.3 1.3 4.8 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 7 7 9 28 1.8 2.5 2.5 3.2 - 20,160 5.9 33,600 9.8 38,640 11.3 1,276 2,411 3,606 5 7 7 7 12 38 1.3 1.9 1.9 1.9 3.2 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 7 7 7 28 2.5 2.5 2.5 2.5 - 20,160 5.9 33,600 9.8 38,640 11.3 1,276 2,411 3,606 5 5 5 9 15 39 1.3 1.3 1.3 2.3 3.9 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 7 12 29 1.7 1.7 2.4 4.2 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 5 12 12 39 1.3 1.3 1.3 3.1 3.1 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 5 15 30 1.7 1.7 1.7 5.1 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 7 7 15 39 1.3 1.3 1.8 1.8 3.9 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 7 9 9 30 1.7 2.4 3.0 3.0 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 7 7 9 9 39 1.8 1.8 1.8 2.3 2.3 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 7 7 9 30 2.4 2.4 2.4 3.0 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 9 9 9 39 1.3 1.8 2.3 2.3 2.3 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 9 12 31 1.6 1.6 2.9 3.9 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 5 7 18 40 1.3 1.3 1.3 1.8 4.6 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 7 7 12 31 1.6 2.3 2.3 3.9 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 9 9 12 40 1.3 1.3 2.3 2.3 3.0 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 7 15 32 1.6 1.6 2.2 4.7 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 7 9 12 40 1.3 1.8 1.8 2.3 3.0 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 7 9 9 32 2.2 2.2 2.8 2.8 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 7 7 7 12 40 1.8 1.8 1.8 1.8 3.0 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 9 9 9 32 1.6 2.8 2.8 2.8 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 7 9 15 41 1.2 1.2 1.7 2.2 3.7 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 5 18 33 1.5 1.5 1.5 5.5 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 7 7 15 41 1.2 1.7 1.7 1.7 3.7 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 7 9 12 33 1.5 2.1 2.8 3.7 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 9 9 9 9 41 1.2 2.2 2.2 2.2 2.2 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 7 7 12 33 2.1 2.1 2.1 3.7 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 7 9 9 9 41 1.7 1.7 2.2 2.2 2.2 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 9 15 34 1.5 1.5 2.7 4.5 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 5 9 18 42 1.2 1.2 1.2 2.2 4.3 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 12 12 34 1.5 1.5 3.6 3.6 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 5 12 15 42 1.2 1.2 1.2 2.9 3.6 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 7 7 15 34 1.5 2.1 2.1 4.5 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 7 7 18 42 1.2 1.2 1.7 1.7 4.3 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 9 9 9 34 2.1 2.7 2.7 2.7 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 9 9 12 42 1.2 1.7 2.2 2.2 2.9 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 7 18 35 1.4 1.4 2.0 5.2 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 7 7 9 12 42 1.7 1.7 1.7 2.2 2.9 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 9 9 12 35 1.4 2.6 2.6 3.5 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 Unités 5 5 9 9 15 43 1.2 1.2 2.1 2.1 3.5 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705 MULTI SPLIT
7 7 9 12 35 2.0 2.0 2.6 3.5 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 7 9 15 43 1.2 1.6 1.6 2.1 3.5 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 7 9 15 36 1.4 2.0 2.5 4.2 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 7 12 12 43 1.2 1.6 1.6 2.8 2.8 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 7 12 12 36 1.4 2.0 3.4 3.4 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 7 7 7 15 43 1.6 1.6 1.6 1.6 3.5 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 7 7 15 36 2.0 2.0 2.0 4.2 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 9 9 9 9 43 1.6 2.1 2.1 2.1 2.1 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
9 9 9 9 36 2.5 2.5 2.5 2.5 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 7 12 15 44 1.1 1.1 1.6 2.8 3.4 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 9 18 37 1.4 1.4 2.5 4.9 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 5 5 24 44 1.1 1.1 1.1 1.1 5.5 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 12 15 37 1.4 1.4 3.3 4.1 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606
5 7 7 18 37 1.4 1.9 1.9 4.9 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 7 9 7 9 7 9 18 44 1.1 1.6 1.6 1.6 4.1 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
34,500
6.1
20,700
12.1
41,400
10.1
2.8
1.1
12
44
2.1
2.1
2.1
2,290
1,277
3,705
7 9 9 12 37 1.9 2.5 2.5 3.3 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 7 9 9 12 44 1.6 1.6 2.1 2.1 2.8 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 9 9 15 38 1.3 2.4 2.4 4.0 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 5 12 18 45 1.1 1.1 1.1 2.7 4.0 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
4 Unités 7 7 9 15 38 1.9 1.9 2.4 4.0 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 5 15 15 45 1.1 1.1 1.1 3.4 3.4 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 7 12 12 38 1.9 1.9 3.2 3.2 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606
5 5 5 24 39 1.3 1.3 1.3 6.2 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 9 9 15 45 1.1 1.6 2.0 2.0 3.4 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 7 9 18 39 1.3 1.8 2.3 4.7 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 7 7 9 7 12 12 45 1.1 1.6 2.0 2.7 2.7 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
1.6
1,277
1.6
10.1
45
12.1
3,705
41,400
15
6.1
3.4
20,700
2.0
34,500
1.6
2,290
5 7 12 15 39 1.3 1.8 3.1 3.9 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 9
9 9 9 12 39 2.3 2.3 2.3 3.1 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 7 7 12 12 45 1.6 1.6 1.6 2.7 2.7 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 7 7 18 39 1.8 1.8 1.8 4.7 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 9 9 9 9 9 45 2.0 2.0 2.0 2.0 2.0 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 12 18 40 1.3 1.3 3.0 4.6 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 5 7 24 46 1.1 1.1 1.1 1.5 5.3 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 9 9 15 40 1.8 2.3 2.3 3.8 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 9 9 18 46 1.1 1.1 2.0 2.0 4.0 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 9 12 12 40 1.8 2.3 3.0 3.0 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 9 12 15 46 1.1 1.1 2.0 2.6 3.3 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 5 7 24 41 1.2 1.2 1.7 5.9 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 12 12 12 46 1.1 1.1 2.6 2.6 2.6 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 9 12 15 41 1.2 2.2 3.0 3.7 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 7 9 18 46 1.1 1.5 1.5 2.0 4.0 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 12 12 12 41 1.2 3.0 3.0 3.0 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 7 12 15 46 1.1 1.5 1.5 2.6 3.3 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 7 12 15 41 1.7 1.7 3.0 3.7 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 7 7 7 18 46 1.5 1.5 1.5 1.5 4.0 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 7 9 18 41 1.7 1.7 2.2 4.4 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 9 9 9 12 46 1.5 2.0 2.0 2.0 2.6 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 7 15 15 42 1.2 1.7 3.6 3.6 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 7 15 15 47 1.1 1.1 1.5 3.2 3.2 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
9 9 9 15 42 2.2 2.2 2.2 3.6 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 9 9 9 15 47 1.1 1.9 1.9 1.9 3.2 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
9 9 12 12 42 2.2 2.2 2.9 2.9 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 9 9 12 12 47 1.1 1.9 1.9 2.6 2.6 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 9 12 15 43 1.6 2.1 2.8 3.5 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 7 9 9 15 47 1.5 1.5 1.9 1.9 3.2 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 12 12 12 43 1.6 2.8 2.8 2.8 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 7 9 12 12 47 1.5 1.5 1.9 2.6 2.6 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 9 9 18 43 1.6 2.1 2.1 4.2 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 5 9 24 48 1.1 1.1 1.1 1.9 5.1 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 9 15 15 44 1.1 2.1 3.4 3.4 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 5 18 15 48 1.1 1.1 1.1 3.8 3.2 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 7 12 18 44 1.6 1.6 2.8 4.1 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 5 7 7 24 48 1.1 1.1 1.5 1.5 5.1 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 7 15 15 44 1.6 1.6 3.4 3.4 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 9 9 18 48 1.1 1.5 1.9 1.9 3.8 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
5 7 18 15 45 1.1 1.6 4.0 3.4 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 9 12 15 48 1.1 1.5 1.9 2.5 3.2 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
9 9 12 15 45 2.0 2.0 2.7 3.4 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 5 7 12 12 12 48 1.1 1.5 2.5 2.5 2.5 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
9 12 12 12 45 2.0 2.7 2.7 2.7 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 7 7 12 15 48 1.5 1.5 1.5 2.5 3.2 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
9 9 9 18 45 2.0 2.0 2.0 4.0 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 9 9 9 9 12 48 1.9 1.9 1.9 1.9 2.5 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 7 7 24 45 1.6 1.6 1.6 5.4 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 7 7 7 9 18 48 1.5 1.5 1.5 1.9 3.8 20,700 6.1 34,500 10.1 41,400 12.1 1,277 2,290 3,705
7 9 12 18 46 1.5 2.0 2.6 4.0 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606
7 9 15 15 46 1.5 2.0 3.3 3.3 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606
7 12 12 15 46 1.5 2.6 2.6 3.3 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606
5 12 12 18 47 1.1 2.6 2.6 3.9 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 Note :
7 7 9 24 47 1.5 1.5 1.9 5.2 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 1. Refroidissement : Intérieur : 27°C BS / 19°C BH, extérieur : 35°C BS / 24°C BH
7 7 15 18 47 1.5 1.5 3.2 3.9 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 2. Chauffage : Intérieur : 20°C BS / 15°C BH, extérieur : 7°C BS / 6°C BH
5 9 15 18 47 1.1 1.9 3.2 3.9 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 3. La capacité totale d’une unité intérieure connectée est de 21k Btu/h
5 12 15 15 47 1.1 2.6 3.2 3.2 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606 4. Au moins 2 unités intérieures doivent être raccordées.
9 9 15 15 48 1.9 1.9 3.2 3.2 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606
12 12 12 12 48 2.5 2.5 2.5 2.5 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606
9 9 12 18 48 1.9 1.9 2.5 3.8 - 20,700 6.1 34,500 10.1 38,640 11.3 1,324 2,545 3,606
